| Specifications |
3T |
| Dead-weight |
2.7T |
| Maximum Operating Radius |
10.5m |
| Standard Configuration |
Diesel Engine and Electric Motor (Dual Power) |
| Maximum Ground Lift |
10.8m |
| Vehicle Size |
3.5m Length × 0.8m Width × 1.85m Height |
| Hook Lifting Speed |
0-8m/min (4 ropes) |
| Specification of Steel Wire Rope |
Φ8mm × 45m |
| Boom Form |
2.4m × 6-section Lifting Arm (Support Customization) |
| Boom Length / Time |
3.1m – 9.2m / 20sec (Support Customization) |
| Boom Angle / Time |
0-78° / 13sec |
| Rotation Angle / Speed |
0-360° (Continuous) / 60sec |
| Outrigger Movement Form |
Manual Screw Out + Hydraulic Support |
| Maximum Extension Amplitude |
4300 (Length) × 3700 (Rear) × 4300 (Front) |
| Walking Mode |
Hydraulic Motor Drive |
| Walking Speed |
0-2.5km/h |
| Gradeability |
25° (36%) |
| Voltage |
AC380V |
| Manufacturer |
Changchai (Support Customization) |
| Type / Displacement |
EV80 / F195 |
| Start Mode |
Electric Start |
| Start Performance |
-5℃ – 40℃ |
| Fuel / Volume |
Diesel Oil / 8L |
| Battery Capacity |
12V 45AH |
| Fuel Consumption |
274g/kW-h |
| Noise Level |
Rated Speed ≤81.5dBA (1m) |
| Operation Type (Boom/Leg) |
Manual Operation, Manual Walking |
| Operational Characteristics |
Manual Operation (Optional Remote Control) |
| Track Size |
220 (Width) × 72 (Pitch) × 50 (Section) |
| Optional Device |
Optional Torque Controller / Remote Control / Hanging Basket / Hydraulic Fly Jib |
